TL450 LRF - Fusion Monocular (Thermal + NV) - OPEN BOX
| Sensor | ||||
|---|---|---|---|---|
| Type | Thermal: Uncooled VOx Infrared Detector, 8 to 14μm; Digital: CMOS | |||
| Resolution | Thermal: 400×300@12μm; Digital: 1920×1080@4μm | |||
| NETD | 30mK | |||
| Frame rate | 50Hz | |||
| Lens | ||||
|---|---|---|---|---|
| Objective lens | Thermal: 50mm, F1.2; Digital: 22mm, F1.5 | |||
| Field of view | 5.5°×4.1° | |||
| FOV m@100m | 10×7 | |||
| Magnification | 3.3x~13.2x | |||
| Detection range | 2600m/2800yd | |||
| Display | ||||
|---|---|---|---|---|
| Display type | 0.39'' AMOLED 1920×1080 | |||
| Color palettes | IR: White Hot, Black Hot, Red Hot, Iron Red, Blue Hot | |||
| Scene modes | Visible: Day, Night, Low-light | |||
| Image modes | IR, Visible, Fusion 1, Fusion 2, Fusion 3 | |||
| Eyepiece | Eye relief: 15 mm; Diopter: -4 to +4; Zoom: 13.8x | |||
| Hardware | ||||
|---|---|---|---|---|
| Laser rangefinder | 600m/650yd | |||
| WIFI | 2.4G | |||
| Interface | USB Type-C | |||
| Others | GPS, Compass, Gyroscope, Bluetooth | |||
| System | ||||
|---|---|---|---|---|
| Recording function | Photo/Video | |||
| Memory capacity | 64GB | |||
| Power | ||||
|---|---|---|---|---|
| Battery type | Single, replaceable 18650 battery | |||
| Operating time | 5 hours | |||
| Environmental | ||||
|---|---|---|---|---|
| Operating temp. | -20°C to 50°C / -4°F to +122°F | |||
| Encapsulation | IP67 | |||
| Physical | ||||
|---|---|---|---|---|
| Weight (g/oz) | 567/20.00 | |||
| Size (mm/in) | 190×70×90/7.48×2.76×3.54 | |||
| Standard | A device, Wrist strap, Battery charger, single 18650 battery, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card | |||
| Optional | Bluetooth remote control, 18650 battery, Dovetail guide | |||
$449.70
Original: $1,499.00
-70%TL450 LRF - Fusion Monocular (Thermal + NV) - OPEN BOX—
$1,499.00
$449.70More Images
